The bus went off route at 3:14 PM. Dispatch called the driver -- no answer. They tried to locate on the GPS map -- the bus icon was frozen from 4 days ago. The telematics unit had lost power Thursday morning and nobody noticed because "no news is good news." The bus was found 90 minutes later by the driver's radio call after the passenger was already agitated. GPS and telematics systems fail silently. Stale data looks identical to live data on a fleet portal map. This is the reference for making sure your fleet visibility is actually current.
Bus GPS & Telematics Inspection Checklist
Verify GPS antenna, LTE modem, wiring, power supply, J1939 interface, firmware, and connectivity across the entire telematics stack -- from roof antenna to cloud dashboard. Applies to school, transit, and coach fleets running Samsara, Geotab, Motive, or vendor-agnostic ELD systems.
Book a 20-Min DemoWhat "Healthy" Actually Means Across the Stack
Before any inspection, memorize what each metric should show on a working unit. Anything below "Warning" means the bus is at risk of untracked movement.
| Signal Metric | Healthy | Warning | Critical |
|---|---|---|---|
| GPS Satellites in View | 8+ SVs | 4-7 SVs | < 4 SVs |
| GPS HDOP | < 2 | 2 - 5 | > 5 |
| LTE RSSI (dBm) | > -85 | -85 to -100 | < -100 |
| LTE RSRP (dBm) | > -95 | -95 to -110 | < -110 |
| Ping Latency | < 50 ms | 50 - 200 ms | > 200 ms |
| Packet Loss | < 1% | 1 - 5% | > 5% |
| Data Uplink Success | > 99% | 95 - 99% | < 95% |
